  • 1.  How to model staggered prices

    TM Forum Member
    Posted 26 days ago
    Hi folks,

    we are trying to model staggered prices in the Product Catalog. The price of Products (instances of a given ProductOffering) depends on the actual value of a ProductCharacteristic (e.g. the size of storage), where the range of possible values is devided into intervals, and the price of the Products depends on the interval; e.g. from 1 to 10 GB there is a different price as from 11 to 30 GB etc.

    I imagin that for the ProductOffering's ProductSpecification there is a ProductSpecificationCharacteristic "size or storage", and a ProductSpecificationCharacteristicValue defining via valueFrom/valueTo that the possible values are in the range of 1GB to 100GB.
    On the ProductOffering side one should then have for each of the intervals a ProductSpecificationCharacteristicValueUse, each defining by a valueForm/valueTo attributes the interval; then one could link different ProductOfferingPrices to each of the ProductSpecificationCharacteristicValueUseValueUse.
    With that the actual Charcteristic.value for a Product could be matched against the ProductSpecificationCharacteristicValueUseValueUse, and the corresponding POPrice coudl be identified.

    The problem is that ProductSpecificationCharacteristicValueUse does not have valueFrom/valueTo attributes.

    Is there any other way to model such a staggered price?
    Or should valueFrom/valueTo be added to ProductSpecificationCharacteristicValueUseValueUse?

    Cheers,
    Lutz

    ------------------------------
    Lutz Bettge
    Deutsche Telekom AG
    ------------------------------


  • 2.  RE: How to model staggered prices

    TM Forum Member
    Posted 25 days ago
    On Jun 9, 2022 9:33 AM @Lutz Bettge wrote:
    > The problem is that ProductSpecificationCharacteristicValueUse does not have valueFrom/valueTo attributes.

    In the schema for ProductSpecificationCharacteristicValueUse there is a simple and a complex way to express values.  You need the latter:

    {
       "@type": "ProductOfferingPrice",
       "prodSpecCharValueUse": [
          {
             "name": "storageSize",
             "productSpecCharacteristicValue": [
                {
                   "valueType": "number",
                   "valueFrom": 1,
                   "valueTo": 100
                }
             ]
          }
       ],
       ...
    }​


    ​​

    ------------------------------
    Vance Shipley
    SigScale
    ------------------------------



  • 3.  RE: How to model staggered prices

    TM Forum Member
    Posted 25 days ago
    Thank you!
    So I have to create a new ProductSpecificationCharacteristicValue on the level of PO, although this is an element that originally should be on the level of PS?
    Not whoiat I would have expected, but I understand that it will work.

    ------------------------------
    Lutz Bettge
    Deutsche Telekom AG
    ------------------------------



  • 4.  RE: How to model staggered prices

    TM Forum Member
    Posted 25 days ago
    Edited by Matthieu Hattab 25 days ago
    removed, duplicate of Vance's response.


  • 5.  RE: How to model staggered prices

    TM Forum Member
    Posted 25 days ago
    Hi,
    my understanding so far is different: "the class name is a bit misleading, it shouldn't contain the term "valueUse" because it doesn't represent values, but characteristics"

    Ig you look at it from the product definition process side, "ValueUse" totally makes sense: You first define the PS with its Characteristics and possible values (e.g. a mobile phone might have "Color" with values "Black", "White", "Gold", and the decide on the PO level that for your specific PO (that you sell to a specific market segment or only thriugh one channel ...) you offer only the "Black" and "White" ones, but not the "Gold", i.e. your PO "uses" only two of the possible values.
    And yes, then you can use the link from the POP to the ValueUse to differentiate the price according to the chosen color.

    My case is then that the Characteristic does not have enumerable values like the color, but is from some range; on PS level I would only express through a Value that the range is from/to; and for one PO I would then like to be able to subdevide the range into intervals, and for each interval to assign a different price; for another PO for the same PS, I might need different intervals.
    Vance in his above solution states that on the PS I would need to have a Value with from/to expressing the whole possible range, and for the PO I would need for each interval a ValueUse, each "containing" a new Value with respective from/to;

    this will work, but the problem that I have with this is that the Value objects "belong" to both levels, that of the PS and the PO; this could easily be avoided if one adds a from/to to the ValueUse, then we do not need the additional Value objects.

    ------------------------------
    Lutz Bettge
    Deutsche Telekom AG
    ------------------------------



  • 6.  RE: How to model staggered prices

    TM Forum Member
    Posted 22 days ago
    Hello,

    I think a graphical product decomposition, would help us all.
    I wonder if you want to price the PO based on characteristic "size of storage" but want to define a price for different brackets. We also call this simple or tiered volume price (or discount)
    This would require to work with 2 different characteristics, one to capture the customer choice and one to store the pricing rule.
    you'd only need the entityValueUse pattern with the POP.

    Matthieu

    ------------------------------
    Kind regards,

    Matthieu Hattab
    Lyse Platform
    ------------------------------
